Pressure Sensor
/
Silicone Resistive Sensor 0.075%
/
JC1002 Gauge Pressure Sensor JC1002
JC1002 Gauge Pressure Sensor JC1002
JC1002 Gauge Pressure Sensor JC1002

JC1002 High Performance Absolute Pressure Sensor

Technical Advantage

The high stability silicon sensor ,  the highest accuuracy is 0.05%
Excellent performance for the overload protection
Packaged temperature sensor inside
Stainless steel 316L and silicon oil filling welded seal structure
